Indoor Rental Led Display P3.91 500x500mm Indoor LED digital music
display high quality video projector screen
P3.91 indoor full color led display cabinet. size:500X500mm.
Not includes the controller system and package.
1.Controller: LINSN,NOVASTAR,etc.
2.Fully Customizable LED Video Wall Systems
3. Three.-Year Signature Warranty
4.Unlimited After-Sales Support by Phone, Email and Temviwer
5.Package: 1-2pcs cabinets---------Carton case.
Beyond 3pcs---------------wooden case/flight case
Advantage:
Support front installation and maintenanace:
After you order,we will provide you the rear service,if you need
front service,please
inform us in advance.
Good flatness for all the led panels:
With an advanced CNC technology.Each panel could be guaranteed to
adopt qualified mold processing to reduce the error in an
infinite approach to zero.
Specifications
| Parameter | Value |
| Pixel Configuration | SMD2020 |
| Pixel pitch (mm) | 3.91 |
| Pixel matrix per panel | 64*64 |
| Pixel density (pixelsm) | 65410 |
| Cabinet Dimensions(L*W) mm | 500*500mm |
| Module Dimensions(L*W) mm | 250*250 |
| Panel material | Aluminum profile&iron&die-casting aluminum |
| Cabinet weight (kg/panel) | 7 |
| Colour grayscale (bit) | 12-16bit |
| Gray scale per colour (level) | 16384 |
| Refresh rate (hz) | 1920 |
| Driving type | 1/16 |
| Signal transmission distance (m) | cats cable:<100m
single mode fiber:<10km |
| Brightness (nit) | 1200 |
| Optimal horizontal viewing angle (degree) | 160 |
| Optimal vertical viewing angle (degree | 160 |
| Ac input voltage (v) | Ac100-240v |
| Ac input frequency (hz) | 50/60 |
| Ac input power maximum value (wm) | 625 |
| Ac input power typical value (wm) | 150 |
| Storage temperature (℃) | -40-60 |
| Work temperature (℃) | 0-45 |
| IP rating (front/rear) | IP40/IP21 |
| Storage humidity (rh) | 10%-90% non -condensing |
Our case
Advantage
1.Thin and light design,one person can handle the installation;
2. 500x500mm big panel, speedily and easily mounting, perfect 16:9
colorful image;
3.Ultra thin body, Die-casting aluminum structure, high-accuracy
connection, error<0.1mm;
4.Natural aluminum heat conduction design (no-cooling fan),quiet
world.
5. Application in concert, exhibition, wedding, conference,
meeting, annual party, DJ bar and other events.
FAQ
Q1. The display will come to me in panel? How to instal them to be one
whole led screen?
Yes, but it's very easy. We will provide structure drawing,
installation diagram and the data connect diagram. and, we also can arrange engineer to your site if you need.
Q2. Can we make any size we want? And What's the best size of led
screen?
Yes, we can design any size according to your size requirement.
Normally, advertising ,stage led screen, The best aspect ratio of
LED display are W16:H9 or W4:H3
Q3. What's the function of video processor?
It can tranfter the video source to make the screen performance
more clear.
And, normally, if led screen connected to computer (DVI Signal)
directly, no need video processor, if want play other kind video
source, such as HDMI, SDI,VGA signal port. that will need.
Or, the HD led screen, its resolution is high. need more than 2pcs
sending card, also need video processor.
Q4. What's the difference between back service and front service led
screen ?
Back service , that mean need enough space behind of the led screen,
so that workder can do the instalaltion or maintenance.
Front servie, worker can do installaion and maintenance from front
directly. very convenience, and save space. especially is that led
screen will fixed on the wall.
