P3.91 Indoor Full Color LED Display Video High Performance Wall
Mount New Imagine
This is the indoor series,but also can be used semi outdoor,we have
all kinds of types,so can provide
you the rich choices.The indoor series we have
P1.667,P1.923,P2,P2.5,P3,P3.91,P4,P5,P6,P10.
And the outdoor series have
P3.91,P4,P4.81,P5,P5.95,P6,P6.67,P8,P10,P12,P16,P20.
By the time,except these tips,we still have other items,like the
Poster screen,transparent screen.
If you have interest,just contact us and we will answer you in 24
hours.
Thank you for your support and welcome to send us your inquiry!!!
Specifications:
| Resolution/mm | 3.91 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 65410/square meter |
| Module resolution | 64*64 |
| Module size/mm | 250*250 |
| View distance | ≥4m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >5000cd/square meter |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | (1/16) |
| Frame rate | 60Hz |
| Refresh frequency | >1000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Maximum power:/square meter | <700W |
| Average power:/square meter | <220W |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Waterproof | IP34 |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC220V/60HZ |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
FAQ
Q. Can this LED display be installed permanently outside? ---A. A
series LED panel is for events use. It has no problem to be used
outdoor for events. But if need long time used outdoor, such as
install on truck or trailer, it is better to buy fixed LED display.
Q. How long time is needed to produce? ---A. Our production time is
7-15 working days. We have 500sqm indoor P3.91 led display stock
now, delivery time is 3 days.
Q. How long does shipping take? ---A. Express and air shipping
usually take 5-10 days. Sea shipping takes about 15-55 days
according to different country.
Q. What trade terms do you support? ---A. We usually do FOB, CIF,
DDU, DDP, EXW terms.
Q. This is the first time to import, I don’t know how to do. ---A.
We offer DDP door to door service, you just need to pay us, then
wait to receive order.
Q. Do I need to buy other equipment to install LED screen? ---A.
You just need to prepare power distribution box, truss and
installation tool. We also offer one stop purchase if you want. We
can also offer stage lights and speaker.
Q.What is LED screen common size? --A. 16:9 and 4:3 aspect ratio is
popular.
