Inside High Pixel P1.923 HD LED Video Display Board Safe Structure
For Hotel / Bank
Features:
1. High pixel, fine and realistic picture quality, pure and bright
colors
2. High flatness, consistent picture
3. High grayscale, studio effect
4. Safety structure
5. Wide viewing angle display technology
6. Dust-proof, moisture-proof, flame-retardant design, safe and
reliable, long service life
7. Back channel maintenance, convenient and fast
Description:
1. P1.667 SMD LED display has high resolution and is suitable for
indoor LED screens;
2. Both horizontal and vertical viewing angles are 140 degrees;
3. P1.667 is increasingly used for electronic digital signage
because the trend of LED screens is high resolution.
4. Advertising images and videos are clear and realistic;
5. High contrast ratio of 1000:1, presenting a real and natural
color LED screen;
Advantages
1) Displaying video motion pictures in high definition
With 4,096 steps of brightness control for each RED, GREEN and BLUE
color,
our system is designed to provide pictures quality similar to that
of analog formula, without losing image data.
2) Displaying multi(natural) colors
With 4,096 color grades of each RED, GREEN and BLUE color, our
system is designed to
display multi-colors amounting 68.7 billion on the screen.
3) Windows based operating software
Our system is designed to be operated with MS Windows.
4) Providing delicate brightness adjustment
Our system is designed to provide delicate brightness adjustment(by
each 0.025% steps)
5) Providing automatic brightness adjustment
Our system is designed to provide automatic brightness adjustment
according to
the change of ambiance brightness.
6) Screen size adjustment
Our system is designed to adjust screen size not only to the
standard ratio of 4 : 3 or 16 : 9
but also specific size as you want to use
Specifications :
| outdoor DIP P1.923 |
| Resolution/mm | 1.923 |
| Pixel configuration | 1R1G1B |
| Pixel density/pixels/m² | 270420/m² |
| Module resolution | 128x128 |
| Module size/mm | 246x246mm |
| View distance | 14-300m |
| Single point brightness adjust | Can be added |
| Single point color adjust | Can be added |
| White balance brightness | >7500cd/㎡ |
| Color temperature | 6500K-9500K |
| Horizontal view angle | 120(degrees) |
| Vertical view angle | 60(degrees) |
| Signal Process bit | 10 or 16bit |
| Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
| Control distances | Internet cable:100m, multimembrane:500m, monofilm:2km |
| Driving mode | Constant driving current |
| Scanning mode | 1/30 SCANNING |
| Frame rate | 60Hz |
| Refresh frequency | >3000Hz |
| Control mode | Computer synchronous |
| Brightness adjusted range | Manual, automatic operation, stepless continuous adjusted |
| 255 steps. No grey loss |
| Out of control point | <1/10000 |
| Working hours | ≥72hours |
| Mean Time Between Failure | >5000hours |
| Life time | 100000hours |
| Life-all-white(brightness halving) | 50000hours |
| Environment temperature range | Operating temperature range: -20-45℃ |
| Self-check technology | LED spot self-check, communications check, power check, |
| temperature monitor(need customization) |
| Remote monitoring | Remote supervision and control, record potential fault, |
| send out warning signs to the operators.(need customization) |
| Software environment | WindowsNT,Windows1999,WindowsXP |
| Luminous point width between centres | Deviation<3% |
| Brightness uniformity | <10% |
| Color uniformity(chromaticity coordinate) | ±0.003 |
| Power supply request | AC85-264V(50Hz-60Hz) |
| Contrast | (1000:1) |
| System protection | Moistureproof,dustproof,high temperature
protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
| Humidity(working) | working:10-95% |
| Humidity(storing) | storing:10-95% |
Packaging & Shipping:
1. Customized packaging. Flight cases, wooden cases and cartons. We
can also help you print your logo on the boxes and the products
themselves.
2. We offer drop shipping services. To ensure you receive your
order tax-free upon import, we declare a lower value.
3. For regular standard cabinet orders, we can ship within 1-2
working days after receiving your sample confirmation and payment;
for large custom OEM orders: we need longer time, about 15-25
working days after receiving your sample confirmation.
FAQ
Q1: What can you buy from us?
A: Rental LED Display, Outdoor LED Display, Indoor LED Display,
Transparent LED Screen, Floor Tile Screen, Creative Design LED
Screen and Etc.
Q2: Can I customize it?
A: Of course. All the goods can be customized, we have a
professional product development team, welcome to customize.
Q3: What is Price per square meter of screen?
A: Welcome to send us inquiry. Our professional sales engineers
will provide suitable solutions.
Q4: What is the warranty?
A: 5-8 years Warranty.
Q5: How many days for producing?
A: 1-3 days for inventory products and 10-15 days for customized
products.
Q6: How to operate and use it?
A: It can by controlled by PC and Smartphone very easily.
Welcome to inquiry for more information. We provide video guidance
and remote assistance.
